Highlights
The optional fastPreheat function heats the oven especially rapidly – without consuming more energy. Waiting time until your oven is ready is reduced to a minimum.
High-quality coating for easy cleaning.
hot air
Perfect baking results on up to 2 baking sheets thanks to optimal heat distribution with hot air.
Extra-large cavity volume with 112 litres allows you to cook all kinds of dishes.
The varioClip rails provide maximal flexibility. Thanks to a quick and easy mounting system you can apply the telescopic rails within your oven at any height.
Additional information
Type of oven / heating system:
- 90 cm built-in oven with 8 heating methods: Hot Air Standard, Conventional cooking, Circulating air, hot air grilling, Full width grill, Bottom heat, Conventional heat gentle
- Cavity volume: 112 l
Hook-in racks / rails
- 1 Clip-on rail
Design:
- Cavity inner surface: enamel grey
Cleaning:
- side, back panel liners
- Full glass inner door
Comfort:
- LED clock and automatic programmer
- Drop down door
- Rapid heating-up
- Elongated halogen light
- Integral cooling fan
Accessory:
- 1 x enamel baking tray, 1 x combination grid, 1 x universal pan
Comfort and Safety:
- Child safety button
Automatic safety switch off
door contact switch
Technical Info:
- Length of mains cable: 115 cm
- Nominal voltage: 220 – 240 V
- Total connected load electric: 3.3 KW
- Energy efficiency rating (acc. EU Nr. 65/2014):
Energy consumption per cycle in conventional mode: 1.19 kWh
Energy consumption per cycle in fan-forced convection mode: 1.27 kWh
Number of cavities: 1
Heat source: electrical
Cavity volume: 112 l
Dimensions:
- Appliance dimension (hxwxd): 594 mm x 896 mm x 570 mm
- Niche dimension (hxwxd): 860 mm – 864 mm x 600 mm – 604 mm x 560 mm
- “Please reference the built-in dimensions provided in the installation drawing”
Technical information
General
| Width (mm) | 896 mm |
|---|---|
| Height of the product (mm) | 594 mm |
| Usable volume (of cavity) – NEW (2010/30/EC) | 112 l |
| Cooking method | Bottom heat, Circulating air, Conventional heat, Conventional heat gentle, Full width grill, Hot air grilling, Rotisserie |
| Highlights | Child-proof Lock |
| Power consumption standby/display on | 0.8 W |
Connectivity
| Home Connect |
|---|
Construction type
| Color / Material Front | Stainless steel |
|---|---|
| Design | Built-in |
| Control Panel Material | Glass, Stainless steel |
| Type of control setting devices – cavity 1 | Rotary knob, round, Touch Control |
| Door Material | Glass |
| Type of heating | Electric hob |
| Installation Type | Built-in |
| Door Opening | Bottom |
Size and weight
| Cavity width (cm) | 72.4 cm |
|---|---|
| Cavity height (cm) | 37.1 cm |
| Cavity depth (cm) | 41.7 cm |
| Dimensions | 594 x 896 x 570 mm |
| Cut-out depth | 560 mm |
| Depth with door open (mm) | 1,029 mm |
| Net weight (kg) | 53.768 kg |
Oven
| Area of largest baking sheet | 1,830 cm² |
|---|---|
| Hot air temperature max. (°C) | 250 °C |
| T/b heating temperature max. (°C) | 250 °C |
| Product size | Large |
| Door temperature | Norm |
Consumption values
| Energy consumption per cycle conventional (2010/30/EC) | 1.19 kWh/cycle |
|---|---|
| Energy consumption per cycle forced air convection (2010/30/EC) | 1.27 kWh/cycle |
Comfort
| Are some hobs controls integrated? |
|---|
Connection
| Length electrical supply cord (cm) | 115 cm |
|---|---|
| Current (A) | 16 A |
| Plug type | no plug |
| Voltage (V) | 220-240 V |
General
| Width (mm) | 896 mm |
|---|---|
| Height of the product (mm) | 594 mm |
| Usable volume (of cavity) – NEW (2010/30/EC) | 112 l |
| Cooking method | Bottom heat, Circulating air, Conventional heat, Conventional heat gentle, Full width grill, Hot air grilling, Rotisserie |
| Highlights | Child-proof Lock |
| Power consumption standby/display on | 0.8 W |
